Odyssey ODX-AGM24M Group 24 AGM Marine Battery

Description

The Odyssey ODX-AGM24M (NSB-AGM24M) is an 12V Extreme Series Group 31 AGM marine and dual purpose battery designed for boats, RVs and heavy duty applications. It delivers high cranking power, fast recovery from deep discharge and excellent vibration resistance.

Compatible With / Replaces

The ODX-AGM24M is a compatible replacement for Group 24 Deep Cycle batteries:

• NSB-AGM24M
• 24DC-AGM
• 24M-AGM
• FT1100-31
• NAU24PLAGM
• NAU24AGM
• SRM24

Key Features

• Extreme starting power – up to 1500A pulse hot cranking amps (PHCA).
• Thin Plate Pure Lead (TPPL) technology for higher power density and faster recharges.
• Deep cycling capability – up to 400 cycles at 80% depth of discharge.
• Maintenance-free, non-spillable design.
• Deep cycle capable for repeated discharge/recharge use.
• Superior vibration and shock resistance – ideal for marine, RV and heavy duty use.
• Long service life in demanding applications with proper maintenance.
• Long storage life – can store for up to 2 years without needing to charge.

Applications

• Marine and trolling systems
• RVs
• Heavy Equipment

Specifications

• Voltage: 12 Volts
• Capacity: 76 Ah
• Pulse (5 second) Hot Cranking Amps: 1,500A
• Marine Cranking Amps: 1,000A
• Cold Cranking Amps: 840A
• Chemistry: AGM
• BCI Group Size: 24
• Length: 10.9″ / 277 mm
• Width: 6.8″ / 173 mm
• Height: 8.2″ / 208 mm
• Height including terminals: 8.8″ / 224 mm
• Weight: 57.1 lbs / 26 kg
• Terminal Type: Dual Terminals – SAE and Stud
• Data Sheet: ODX-AGM24M Specifications (PDF)

The Odyssey ODX-AGM24M is an excellent choice for marine, RV and commercial applications requiring high cranking power, deep cycle performance and long service life.
