Group 140R AGM Car Battery (H4/L1)

Description

The Group 140R AGM car battery (H4 / L1) delivers 400 Cold Cranking Amps (CCA) and a 75-minute reserve capacity for dependable everyday starting power. Its AGM design supports modern vehicles with start-stop systems and demanding electrical accessories.

Not sure whether your battery needs replacing? We offer a free in-car battery diagnostic.

Replacement Part Numbers

A replacement option for the following part numbers. Confirm dimensions, terminal position and your vehicle’s battery requirements before purchasing.

• 9AGM140R
• 140R-650AGM
• GH4AGM
• LN1AGM
• 140R-TCAGM
• H4-AGM
• MTX-140R/H4
• MTZ-140R/H4
• SLI140RAGM
• YBX9140R
• Suitable for select BMW auxiliary battery applications requiring a Group 140R / H4 / L1 AGM battery.
• Select Toyota Prius and Prius Prime models requiring a Group 140R / H4 / L1 AGM battery.

Key Features

• AGM technology: Sealed, maintenance-free design.
• Spill-Proof  & Leak Resistant – reduced risk of acid spills and corrosion compared to conventional flooded batteries.
• 400 CCA: Dependable starting power in cold weather.
• Start-stop capable: Designed to support frequent engine starts.
• Vibration resistance: Built to handle everyday driving demands.

Important: If your vehicle was originally equipped with an AGM battery, use an AGM replacement that meets the vehicle manufacturer’s specifications.

Specifications

• Voltage: 12 Volts
• BCI group size: 140R
• Alternate size designations: H4/L1
• Battery type: AGM starting battery
• Cranking Amps (CA):500
• Cold Cranking Amps (CCA): 400
• Reserve Capacity Minutes (RC): 75 minutes @ 25 Amps
• Terminal Type: SAE Automotive top posts

Dimensions

• Length: 8.2″ / 208 mm
• Width: 6.8″ / 173 mm
• Height: 7.5″ / 190 mm
• Weight: 33 lbs / 15 kg

Frequently Asked Questions

Are Group 140R, H4 and L1 the same battery size?
These designations refer to the same general battery size. Confirm dimensions, terminal layout and your vehicle’s battery requirements before purchasing.

Can I replace my original AGM battery with a flooded battery?
If your vehicle was originally equipped with an AGM battery, use an AGM replacement that meets the manufacturer’s requirements.

Will this battery fit my vehicle?
Check your vehicle’s recommended battery size, technology and starting specifications. If you are unsure, contact us with your vehicle’s year, make, model and engine size for help selecting a battery.

Can you test my current battery?
Yes! We offer a free in-car battery diagnostic at our Toronto store to help determine whether your battery needs replacing.
